RF-Power3000 50Mhz-3000Mhz OLED RF Power Meter -45dBm~+5dBm 1nW-2W Adjustable Attenuation Value - 28.99 €

Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)

Free shipping aviable, Registered postage from 25 €

RF-Power3000 50Mhz-3000Mhz OLED RF Power Meter -45dBm - +5dBm 1nW-2W Power Adjustable Attenuation Value

Description

Measuring power range: -45 ~ + 5 dBm (external RF attenuator can be extended to 100dBm)

Measurement resolution: 0.1 dBm

Measurement frequency range: 50 ~ 3000 MHz

Measured power: 1nW ~ 2W

Working voltage: 5V DC (can work MICRO-USB powered)

Working current: <50 mA

Working temperature: -40 â ~ 65 â

Storage temperature: -40 â ~ 65 â

Size(L*W*H):50 x 50 x 25 mm

Product application:

1.Low RF power measurement

2.Low calibration instrument

Feature:

0.96 Inch OLED display, PC to read data and Settings, can set the frequency point, preset attenuation, simple structure, convenient use, stable performance, reliable, high sensitivity and fast measurement, etc.

Operation:

1.Set by the upper machine frequency value

2.Instrument above contains four buttons, respectively is: up, down, left, right, sure touch four switches. Is to move the cursor around with, is add and subtract values with up and down.

RF Common Sense Science:

1.dB is a pure count of unit:

For power, dB = 10 * lg (A / B).

For voltage or current, dB = 20 * lg (A / B).

2.dBm is defined miliwatt (mW). 0 dBm = 1mw;

dBw defined watt. 0 dBW = 10lg1 W = 10lg1000 mw = 30 dBm.

3.dB power units are always defined by default, to 10lg for scoring. Of course, some cases may signal strength (Amplitude) to describe the work and power, this time with 20lg for scoring. Whether in the field or control signal processing field like this. For example, sometimes you can see the expression dBmV.

Package Included:

1 x RF Power Meter

Note:

Manual measuring, please allow 1 ~ 3 mm error,thank you.
