Description:
This Runcam FPV camera is specially for RC drone. 2MP image resolution and 1080P / 720P video resolution supports a clearer image, let you capture clearer world and moment. 130 degree and 165 degree switchable FOV angle of field, meet your different needs.
Main Features:
â 1080P 60fps HD recording WDR FPV camera
â Power-off protection for video files
â Low latency TV-OUT
â Wide voltage ( 5 - 17V )
â Anti-drop SD card
Specifications:
FOV angle of field: FPV FOV 130 degree / recording FOV 165 degree
Video resolution: 1080P 60fps / 1080P 30fps / 720P 60fps
Video files: MOV
Image resolution: 2MP
TV output system: NTSC ( 720 x 480 ) / PAL ( 720 x 576 ) switchable
Interface: Micro USB / UART
Max micro SD card supported: 64G ( need class 6 or above, recommend Class 10 / UHS-I / UHS-II )
Hole distance of installation: 20 x 20mm
Power input: DC 5 - 17V / DC 5V ( USB )
Working current: 650mA 5V / 270mA 12V
This Runcam FPV camera is specially for RC drone. 2MP image resolution and 1080P / 720P video resolution supports a clearer image, let you capture clearer world and moment. 130 degree and 165 degree switchable FOV angle of field, meet your different needs.
Main Features:
â 1080P 60fps HD recording WDR FPV camera
â Power-off protection for video files
â Low latency TV-OUT
â Wide voltage ( 5 - 17V )
â Anti-drop SD card
Specifications:
FOV angle of field: FPV FOV 130 degree / recording FOV 165 degree
Video resolution: 1080P 60fps / 1080P 30fps / 720P 60fps
Video files: MOV
Image resolution: 2MP
TV output system: NTSC ( 720 x 480 ) / PAL ( 720 x 576 ) switchable
Interface: Micro USB / UART
Max micro SD card supported: 64G ( need class 6 or above, recommend Class 10 / UHS-I / UHS-II )
Hole distance of installation: 20 x 20mm
Power input: DC 5 - 17V / DC 5V ( USB )
Working current: 650mA 5V / 270mA 12V
Specification
General |
Brand: RunCam
FPV Equipments: FPV Mini Camera Functions: Video |
---|---|
FPV Goggles |
TV System: NTSC / PAL Switchable |
Dimension and Weight |
Product weight: 0.0150 kg
Package weight: 0.0300 kg Product size (L x W x H): 2.90 x 2.70 x 1.00 cm / 1.14 x 1.06 x 0.39 inches Package size (L x W x H): 5.00 x 5.00 x 5.00 cm / 1.97 x 1.97 x 1.97 inches |
Package Contents |
Package Contents: 1 x Mini FPV Camera, 1 x Metal Cover, 1 x SD Card Protector, 1 x Bracket, 1 x Cable, 1 x 3 Pin FPV Silicone Cable ( Male ), 1 x 3 Pin FPV Silicone Cable ( Female ), 1 x Set of Screws |
