Skywing TS1500 5.8G 1500mW 48CH AV Transmitter FPV VTX for FPV


Description:
MODE:TS1500 Modulate Wideband FM Modulate Video Format NTSC/PAL Characteristics Value Units Min. TYP. Max. Output Impedance --- 50 --- Ohm Output Power 29.5 30 30.5 dBm Operating Voltage 7.0 12 30 V Supply Current --- 680 --- mA Operating Temperature -10 --- +85 ℃ Video Band Width 0 --- 8.0 MHz Audio carrier Frequency --- 6.5 --- MHz Video Input Level 0.8 1.0 1.2 Vp-p Video Input Impedance --- 75 --- Ohm Audio Input Level 0.5 2.0 Vp-p Audio Input Impedance --- 10k --- Ohm Weight --- 35 --- g Antenna Connector RPSMA Connector Dimensions(L x w x H) 58*33*12mm
Button Instruction and Frequency channel table
short press key FR choose 1 2 3 4 frequency group.
short press key CH choose 1 2 3 4 5 6 7 8 frequency point.


CH
FR CH CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 FR FR1(A) 5865MHz 5845MHz 5825MHz 5805MHz 5785MHz 5765MHz 5745MHz 5725MHz FR2(B) 5733MHz 5752MHz 5771MHz 5790MHz 5809MHz 5828MHz 5847MHz 5866MHz FR3(C) 5705MHz 5685MHz 5665MHz 5645MHz 5885MHz 5905MHz 5925MHz 5945MHz FR4(D) 5740MHz 5760MHz 5780MHz 5800MHz 5820MHz 5840MHz 5860MHz 5880MHz FR5(H) 5658MHz 5695MHz 5732MHz 5769MHz 5806MHz 5843MHz 5880MHz 5917MHz FR6(L) 5362MHz 5399MHz 5436MHz 5473MHz 5510MHz 5547MHz 5584MHz 5621MHz
Connection Method
Line 1:VDD_IN(7-30V) Line 1
Line 2
Line 3
Line 4
Line 5
Line 2:GND Line 3:VIDEO_IN Line 4:VDD_OUT(5V) Line 5:GND

Features:
Different from the other transmitter, it wouldn't be burned if the power cables were reverse or forgot to connect the antenna when you power on it.
Aluminum alloy shell design, with better cooling function
It is the smallest transmitter of same power VTX
Transmitter distance can be up to 8-10 kilometer.
Package Included:
1 x Transmitter
1 x Antenna
1 x Cable
