Skyzone SKY02S V+ 3D 5.8G 40CH FPV Goggles With Transmitter 120 Degree Camera Head Tracking HDMI DVR Playback
Description:
Brand Name: Skyzone
SKY02S 3D FPV Goggles
Binocular Display: FOV: 30 degree(Diagonal)
Resolution: 854x480(WVGA).1,229,760 color sub-pixels
Brightness: 350cd/ã¡
Interpupillary Distance(IPD): 59-69MM Adjustable
Sensitivity: -90dBm±1dBm
Antenna: SMA 50ohm
Front Camera: FOV: 60 degree(Diagonal)
Resolution:640x480(VGA)
Focal Length: f=4.0mm
F/NO:=2.8
Head Tracker: Sensor: Magnetic,Inertial and gyro
Output: PPM 8CH, Optional 5â6CH,5â7CH,5â8CH,6â7CH,6â8CH,7â8CH
Micro SD: Support to 32GB
Compression: MJPEG, 30fps, AVI
Picture: JPEG
Record Rate: 6Mbps
Video Standard: NTSC/PAL
Video output level: 1.0Vpâp Typ. / 75ohm
Audio output level: 1.0Vpâp Typ. / 10Kohm
Div. AV OUT(3.5mm4P): Diversity Video, Audio output
EAR OUT(3.5mm3P): Stereo 16Ω/150mW
AV IN(3.5mm4P): Video ,Audio input
HDMI IN(Micro HDMI/DâType): HDMI 1.4 specification
1920x1080p60, 1920x1080p50, 1920x1080i60, 1920x1080i50,
1280x720p60, 1280x720p50, 576p, 576i, 480p, 480i, PC Format(Not all)
DC IN: DC 7~26V/ 1A
Power Consumption: 12V input, 5.4W
Dimensions: 168(L)X92.5(W)X41(H)MM
Operating Temperature: 0 â~+60
SCAM302 Camera:
FOV: 120 degree(Diagonal)
F/NO: =2.3
Interpupillary Distance(IPD): 40mm
Resolution: 720x576
Video Standard: PAL
Video Output Level: 1.0Vp-p Typ./75ohm
Power Supply: DC5V/0.5A
Power Consumption: 1.6W
Dimension: 56.5x 17.8x14mm
Weight: 12g
Operating Temp.: 0â~+60â
STX202 Transmitter:
Wideband FM Modulate
Video Standard: NTSC/PAL
RF Output Impedance: 50ohm
RF Output Power: 22-24dBm(Typ.23dBm)
Video Input Level: 1.0Vp-p Typ./75ohm
Video Band Width: 8.0MHz
Audio Input Level: 2.0Vp-p Typ./10Kohm
Audio Carrier Frequency: 6.5MHz
Power Consumption: 5V input 5.5W
Dimension: 38x 32x8.9mm
Weight: 14g
Operating Temp.: 0â~+70â
Preset Frequency: CH1 5733M/5771M, CH2 5752M/5790M, CH3 5809M/5847M, CH4 5828M/5866M
Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725
Frequency Band B 5733 5752 5711 5790 5809 5828 5847 5866
Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725
Frequency Band B 5733 5752 5711 5790 5809 5828 5847 5866
Frequency Band E 5705 5685 5665 5645 5885 5905 5925 5945
Frequency Band F 5740 5760 5780 5800 5820 5840 5860 5880
Frequency Band R 5658 5695 5732 5769 5806 5843 5880 5917
RF Mode:
3D Mode, only available under the RF mode.
2D Mode
Features:
Front Camera, more convenience
Image Adjustment, can set the brightness, contrast, hue, sharpness etc.
With Head Tracking, pan and tilt
With DVR function, suggest to format the SD card the first time you use
Playback function
HDMI Input
AV Output/Input
Package Included:
1 x Goggles
1 x SCAM302 Camera
1 x STX202 Transmitter
1 x Futaba Data Cable
1 x JR Data Cable
1 x WFLY Data Cable
4 x 5.8G 2dBi Antenna
1 x 5P Camera Cable
1 x 3P TX Remote Control Cable
1 x AV Cable
1 x Power Cable
1 x 2P TX Power Cable
