TOBYRICH TR1 5.8G 40CH Diversity FPV Goggles 5 Inch 800*480 Video Headset HD DVR Build in 1200mAh Battery For FPV Racing Drone
Description :
Brand Name : TOBYRICH
Item Name : TR1
|
Appearance |
Dimension: 180*145*82mm Weight: 362g without antenna Belt : three-way adjustable belt |
|
Specification |
Build in DVR Record up to 720*576px full frame rate video, no frame lost (C10 card required) Re play in MENU Require C10 card to record full frame rate |
|
Diversity |
-90dB Super sensitiveness in 2pcs RX5808 PRO modules Great performance when two types (Linear and Omni) antennas are used |
|
Display |
Screen size: 5.0 inch Screen resolution: 800*480(No blur after enlarge by the lens) Screen brightness: 600cd/m2 with special high brightness backlight LED for outdoor FPV Ratio : 16:9, 4:3 View Angle: 140/120 degree(Horizontal/Vertical) |
|
Lens |
3x boost of the video to acquire intense feel-in-there video; 92% transparent rate distort if light; |
|
Battery |
Built-in 3.7V/1200mAh battery; Each battery circle offer around 2hr working time; 5V-15V wide range recharging voltage range, typical recharging voltage is 12V Charger : 5V-15V,2A, DC 2.5mm |
Frequencies (5.8GHz, with RaceBand)
| CH | CH 1 | CH 2 | CH 3 | CH 4 | CH 5 | CH 6 | CH 7 | CH 8 |
| GROUP | ||||||||
| A or FR1 | 5865 MHZ | 5845 MHZ | 5825 MHZ | 5805 MHZ | 5785 MHZ | 5765 MHZ | 5745 MHZ | 5725 MHZ |
| B or FR2 | 5733 MHZ | 5752 MHZ | 5771 MHZ | 5790 MHZ | 5809 MHZ | 5828 MHZ | 5847 MHZ | 5866 MHZ |
| C or FR3 | 5705 MHZ | 5685 MHZ | 5665 MHZ | 5645 MHZ | 5885 MHZ | 5905 MHZ | 5925 MHZ | 5945 MHZ |
| D or FR4 | 5740 MHZ | 5760 MHZ | 5780 MHZ | 5800 MHZ | 5820 MHZ | 5840 MHZ | 5860 MHZ | 5880 MHZ |
| R or FR5 | 5658 MHZ | 5695 MHZ | 5732 MHZ | 5769 MHZ | 5806 MHZ | 5843 MHZ | 5880 MHZ | 5917 MHZ |
Features:
Built-in with super HD DVR record up to 720*576px resolution
Diversity RaceBand 40ch Auto-Searching
Two system (Display/Record duo core separated chipsets ) ensure no delay in displaying and no frame lost in recording(please use C10 super speed card to ensure the full frame recording)
Work friendly with p ilot-OSD, no block on the important flying OSD information;
Separable design, 5 inch screen can be used as small monitor on radio controller or with tripod;
HD high brightness 5 inch LCD specially tuned for FPV racing;
Diversity function, Built-in super sensitive 5.8GHz 40ch receiver module, with RaceRand;
Advanced auto-searching function and the working frequency show on screen;
Built-in 3.7V 1200mAh double chips battery, each full charge offer 2 hours working time;
Wide range re-charge voltage 11-20V;
Accept 2S or 3S batteries as back-up power source, to prolong the working time;
Nice ergonomic design and fit different faces;
Super-wide visible angle up to 82 degree;
92% transparent lens adopted, no distort, no blur on the edge of screen;
Light weight 375g with 3.5 hr 1200mAh battery, RTF for any scale racing game;
5 Inch 800*480px HD high brightness LCD
Package Included :
1 x TOBYRICH TR1 40CH 5.8G Diversity Goggles with DVR
2 x Linear Antenna
1 x Battery Charger
1 x 3S to DC Power Cable
1 x User Manual
1 x Clean cloth
1 x Bag
