Specifications:
Input voltage: 2.8V-4.2V (supports 1 lithium battery)
Continuous working current: 3A
Instantaneous current: 4A (less than 10 seconds)
BEC output: None
Dimensions (length x width x thickness): 11x13x8 mm
Weight: 0.7 g
Features:
1. Adopt high-speed, small-sized MCU with powerful functions.
2. With low voltage protection; over temperature protection; throttle signal loss protection; motor starting protection and so on.
3. Soft start, good starting performance, good throttle linearity, fast throttle response, very good low speed performance.
4. The maximum supported speed is: 240,000 rpm (2 magnetic poles), 80,000 rpm (6 magnetic poles), 40,000 rpm (12 magnetic poles).
5. Multiple parameters of the governor can be set through the remote control. Throttle stroke can be set to be compatible with different receivers.
Parameters that can be set using the programming card:
1. Brake type: three options: no brake, soft brake, hard brake. The default is no braking. Soft braking means less braking force and longer braking time, while hard braking means more braking force and shorter braking time.
2. Electronic timing: three options: low timing, middle timing, high timing. The default is the middle angle. Low timing is suitable for motors with large inductance and low speed; high timing is suitable for outer rotor motors with small inductance and high KV value. For some high-KV motors, if the motor shakes at high speed during use, it needs to be changed to a high timing.
3. Start mode: three options: fast start, soft start, super soft start. The default is super soft start. Fast start is suitable for motors with small inductance and small starting load; Ultra-soft start is suitable for motors with large inductance and large starting load; soft start is somewhere in between.
4. Cut-off type: Two options: reduce power (soft cut-off), immediate shutdown (hard cut-off). The default is reduced power. Protective treatment when the battery voltage is too low. Choose to shut down immediately, and turn off the motor immediately when low voltage occurs. Choose to reduce power consumption. If the voltage is too low, the output power will be gradually reduced to 50% of the current power (that is, the power when there is no low voltage).
5. Low voltage protection threshold: 2.8V, 3.0V, 3.1V three kinds of voltage can be selected, the default is 2.8V.
Package included:
1 x XSTAR xp-3A 0.7g Ultra Light Brushless ESC Electronic Speed Control for RC Airplane Spare Part
Package included:
1 x XSTAR xp-3A 0.7g Ultra Light Brushless ESC Electronic Speed Control for RC Airplane Spare Part
