ZTW Mantis Series 45A SBEC 5A Brushless ESC For RC Airplanes & Helicopters - 24.69 €

ZTW Mantis Series 45A SBEC 5A Brushless ESC For RC Airplanes & Helicopters
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

ZTW Mantis Series 45A SBEC 5A Brushless ESC For RC Airplanes & Helicopters



Description:
ZTW Mantis series ESC is a medium level product line designed for fixed wing and Helis. This product line cover wide range of product to meet various customer needs from 6A to 155A including OPTO HV version.It’s performance and stability have been approved by distributors and pilots around the world. It features compact size, light weight, fashion design, super smooth start up and throttle linearity, multiple protection, governor, strong BEC output etc. All these feature make this product line a perfect intermediate level for the park, sports, aerobatic pilots.

Specification:
Brand Name: ZTW
Series: Mantis
Continuous Current: 45A
Burst Current (10s): 65A
Battery: 5-18NC/2-6 Lipo
BEC Output: 5V 5.5V 6V Adjustable/5A
Length: 57mm
Width: 31mm
Height: 12mm
Weight: 47g

Features:
Supports high RPM motors,can be used with most of the motors in the rc market .
Secondary sub-menu setting ,is easier to be programmed .
Adjustable BEC output 5.0V/5.5V/6.0V and Continuous 5A current (supplies the Servo with much stronger power)
Advanced Governor Mode ( has the B-Series ESC to keep the motor speed even though the load is changed)
More optional motor timing Setup and soft acceleration start ups ( make the motors run smoothly)
Super smooth and accurate throttle linearity
Power arming protection (prevents the motor from accidentally running when switched ON)
Auto throttle shut down in signal lose situation
Safety thermal over-load protection, when the temperature of ESC exceeds 110 deg C,the ESC will reduce the output power to allow it to cool.
Use new generation of the MOSFET to ensure ESC's heating low,supporting biggest Peak current and higher reliability .
3.1 New Advanced programming software

English Manual,

Package Included:
1x ZTW Mantis 45A SBEC 5A ESC
