Eachine TRASHCAN 75mm Crazybee F4 PRO OSD 2S Whoop FPV Racing Drone Caddx Eos2 Adjustable Camera 25/200mW VTX - Durable
Specifications:
Brand Name: Eachine
Model Name: TRASHCAN
Item Name: 2S 75mm Brushless Whoop racer drone BNF/PNP
Wheelbase: 75mm
Size: 98mm*98mm*36mm
Weight: 33g(without battery)
Weight:48g(with Original 1s 300mah lipo battery x2)
Spare parts specifications:
| Motor | Mode: TC0803 KV16000 Configu-ration: 9N12P Stator Diamter: 8mm Stator Length: 3mm Shaft Diameter: Φ1mm Motor Dimension(Dia.*Len): Φ10.5mm*14.5mm Weight(g): 2.2g No.of Cells(Lipo): 1S-2S |
| Flight controller | (Frsky version) CRAZYBEEF4 PRO FR Firmware target: CrazybeeF4FR (Flysky version) CRAZYBEEF4 PRO FS Firmware target: CrazybeeF4FS (DSM2/DSMX version) CRAZYBEEF4 PRO Firmware target: CrazybeeF4DX (No RX version) CRAZYBEEF4 PRO FR Firmware target: CrazybeeF4DX MCU: STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000(SPI connection) Board size: 28.5 * 28.5MM Power supply: 1-2S battery input (DC 3.5-8.7V) Built-in 6A(each) Blheli_S 4in1 ESC Dshot600 ready Frsky version Built-in SPI Frsky receiver with telemetry(D8/D16 switchable) Flysky version Built-in SPI Flysky receiver with telemetry(AFHDS/AFHDS2A switchable) DSM2/X Version built-in Serial-based DSM2/DSMX compatible satellite receiver No RX version need to add external Receiver Built-in Betaflight OSD(SPI Control) Built-in Current meter Max 28A Current meter scale set to 1175 Built-in 5V 1A Buck / Boost with LC filter Built-in voltage detection BLHELI_S pass-through Ready Taillight LED Ready |
| Onboard 4in1 ESC | MCU upgraded to EFM8BB21 Power supply: 1-2S LiPo/LiPo HV (3.5v/8.7v) Current: 6A continuous peak 7A (3 seconds) Support BLHeliSuite programmable Factory firmware: S_H_50_REV16_7.Hex Default protocol: DSHOT600 |
| Frsky NON-EU receiver Version | SPI BUS receiver Frsky D8/D16 switchable Compatible Non EU transmitter both D8 and D16 mode Channels: 8ch or 16ch Failsafe support No ground interference ( Transmitter and receiver 1 m from the ground): 300m |
| Flysky receiver Version | SPI BUS receiver Protocol: AFHDS and AFHDS-2A Switchable Channels: 8ch(AFHDS) or 14ch(AFHDS-2A) No ground interference ( Transmitter and receiver 1 m from the ground): 300m Failsafe support |
| DSM2/DSMX receiver version | Serial bus receiver Protocol: DSM2/DSMX compatible Channels:6-9 (Depend on your radio) No ground interference ( Transmitter and receiver 1 m from the ground): 300m |
| PNP No RX version | No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc. |
| VTX | Output power: 25/200mw switchable Frequency: 40CH Input voltage: 3.3V 5.5V Current consumption: 300mA(type) Antenna: RG178 antenna Frequency: 5.8GHz 5bands 40 channels With Raceband Smart Audio ready Weight: 3g |
| CADDX EOS2 camera | 1/3" CMOS Sensor 1200 TVL 2.1mm lens 16:9 Image size NTSC Global WDR Internal Synchronization |
| Lipo Battery | Capacity: 300mAh Voltage: 3.8v Continuous Discharge Rate: 40C Instantaneous discharge rate: 80C Size: 55mmx11.5mmx6.5mm Weight: 7.8g Connector: PH2.0 *Notes: Need 2pcs batteries for Series circuit |
Features:
PNP version support TBS receiver
New Crazybee F4 PRO Flight controller 1-2s Lipo Compatible
2S whoop more powerful and more flight time
Betaflight support , multi flight mode: ACRO/AIR/ANGLE
New 0803 Powerful and High efficiency Brushless motor and Smooth ESC. The motor power with 7V and 40mm propeller can get 55g pull. It is more powerful pull than 0802 49g.
Betaflight OSD support ,easy to get RSSI, Voltage ,current from your goggles(DSMX version no RSSI output)
Caddx EOS2 camera ready , More comfortable FPV experience
Camera Angle adjustable (0-35°)
VTX power switchable 25mw~200mw
Smart Audio ready , change VTX bands, powers, channels via OSD
Adjust the settings and the PID of the flight controller via OSD
Frsky Non-EU version support NON-EU Frsky transmitter D8/D16 compatible
Flysky version support both AFHDS and AFHDS-2A protocol transmitter
DSM2/DSMX version support DSM2 and DSMX compatible Spektrum transmitter
No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc..
Full telemetry function ready (Frsky Non-EU and Flysky version support)
Support buzzer
LED_Strip Ready
Real Bind and Fly version
Compatible both for 1s-2s
Package Included:
PNP/ NO Receiver Version
1 x 75mm Brushless whoop Frame
1 x Crazybee F4 PRO FC no RX verion
4 x TC0803 KV16000 Motor
1 x 40mm propeller(4cw+4ccw)
1 x Caddx EOS2 camera
1 x 5.8G 40ch 25mw-200mw VTX
4 x 3.8v 300mah 40C/80C battery
1 x USB Lipo/LIHV Charger
1 x Propeller disassemble tool
1 x LED board
1 x Screwdriver
1 x XT30 wire
1 x Bag
BNF Version
1 x 75mm Brushless whoop Frame
1 x Option1: Crazybee F4 PRO FC built-in Frsky NON-EU receiver
Option2: Crazybee F4 PRO FC built-in Flysky AFHDS and AFHDS-2A Switchable receiver
Option3: Crazybee F4 PRO FC built-in DSM2/DSMX receiver
4 x TC0803 KV16000 Motor
1 x 40mm propeller(4cw+4ccw)
1 x Caddx EOS2 camera
1 x 5.8G 40ch 25mw-200mw VTX
4 x 3.8v 300mah 40C/80C battery
1 x USB Lipo/LIHV Charger
1 x Propeller disassemble tool
1 x LED board
1 x Screwdriver
1 x XT30 wire
1 x Bag
