Specification of Toolkitrc M6:
Input Voltage: DC 7-28V
Output Voltage: 1-28V
USB Output: 5V 2.1A
Charge Current: 0.1-10A
Discharge Current: 0.1-2A(Recycling mode)
0.1-10A(Internal consumption mode)
Max Charge Capacity: 150W
Max Discharge Capacity: 20W
Supported Batt. Type:LiFe/Lilon/LiPo/LiHv (1-6S)
NiMH/Cd(1-16S)
Pb(1-10S)
Size:68*49*26 mm
Weight: 80g
Feature of Toolkitrc M6:
1.The M6 charger come with LCD Display
2.Charge, discharge and balance management support Lipo, LiHV ,LiFe,Lion 1-6S, NiMh 1-16s ,Pb 1-12S battery
3.Can measure battery voltage, battery internal resistance, balance
4.Can measure PWM / PPM / SBUS / DBUS and other signal values accuracy 1s.
5.Can output PWM / PPM / SBUS standard signal, accuracy 1s.
6.Customizable 1-28V constant voltage,1-10A constant current.
7.Compatible with iOS and android mobile device.
8.Charge the drone battery,active and charge.
9.USB [email protected] Output,for mobile phone devices.
10.Udisk firmware upgarde.(Slave device).
11.Multi-language support.
12.TFT 1.8"Full color LCD.
13.150w 10A Charging capacity.
14.0.1a to 10A Discharge/Storage mode with Energy recycle function (high amp discharge and storage when using a battery as the power source.
15.PWM Signal generating function for servo testing.
16.User controlled Power Supply mode with adjustable voltage and amperage output.
17.Cell balancing and IR testing mode.
18.Easy Firmware update, charger acts like USB drive then just copy and past firmware file.
Description of charger board:
Item Name: Amass XT60 Para Board
Compatible for iSDT D2 Q6 SC-608 SC-620 Charger
Balance Cells: 2s~6s
Plug: XT60
Packaging Included:
1X ToolkitRC M6 Charger
1x Amass XT60 Plug Parallel Charging Board
